P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B121
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Secondary
[Indexed String]
This setting controls whether measured values via the rear communication port are displayed as primary or secondary quantities.
Measurement Ref 0D 04 VA
VA
VB
VC
IA
IB
IC
[Indexed String]
Using this setting the phase reference for all angular measurements by the IED can be selected. This reference is for Measurements 1.
Measurements 3 uses always IA local as a reference
Measurement Ref 0D 04 VA
VA
VB
VC
IA
IB
IC
[Indexed String]
Using this setting the phase reference for all angular measurements by the IED can be selected. This reference is for Measurements 1.
Measurements 3 uses always IA local as a reference
Measurement Mode 0D 05 0
From 0 to 3 in steps of 1
[Unsigned Integer (16 bits)]
This setting is used to control the signing of the real and reactive power quantities.
Fix Dem Period 0D 06 30
From 1 to 99 in steps of 1
[Courier Number (time-minutes)]
This setting defines the length of the fixed demand window
Roll Sub Period 0D 07 30
From 1 to 99 in steps of 1
[Courier Number (time-minutes)]
These two settings are used to set the length of the window used for the calculation of rolling demand quantities
Num Sub Periods 0D 08 1
From 1 to 15 in steps of 1
[Unsigned Integer (16 bits)]
This setting is used to set the resolution of the rolling sub window
Distance Unit 0D 09 Miles
Kilometres
Miles
[Indexed String]
This setting is used to select the unit of distance for fault location purposes, note that the length of the line is preserved when converting
from km to miles and vice versa
Fault Location 0D 0A Distance
Distance
Ohms
% of Line
[Indexed String]
The calculated fault location can be displayed using one of several options selected using this setting
Remote2 Values 0D 0B Primary
Primary
Secondary
[Indexed String]
The setting defines whether the values measured via the Second Rear Communication port are displayed in primary or secondary terms.
COMMUNICATIONS
0E
00
This column contains general communications settings
RP1 Protocol 0E 01
Courier
IEC870-5-103
Modbus
DNP 3.0
[Indexed String]
Indicates the communications protocol that will be used on the rear communications port.
RP1 Address 0E 02 255
From 0 to 255 in steps of 1
[Unsigned Integer (16 bits)]
Courier or IEC60870-5-103 versions only. Sets the address of Rear Port 1
RP1 Address 0E 02 1
From 0 to 65519 in steps of 1
[Unsigned Integer (16 bits)]
