P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B123
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
10-bit no parity
[Indexed String]
Courier versions only. The choice is either IEC 60870 FT1.2 for normal operation with 11-bit modems, or 10-bit no parity.
RP1 Baud Rate 0E 0E 19200 bits/s
9600 bits/s
19200 bits/s
38400 bits/s
[Indexed String]
Courier versions only. This cell controls the communication speed between IED and master station. It is important that both IED and master
station are set at the same speed setting.
Meas Scaling 0E 0F Normalised
Normalised
Primary
Secondary
[Indexed String]
DNP 3.0 versions only. Setting to report analogue values in terms of primary, secondary or normalized (with respect to the CT/VT ratio
setting) values.
Message Gap (ms) 0E 10 0
Message Gap (ms)
[Courier Number (time-milliseconds)]
DNP 3.0 versions only. This setting allows the master station to have an interframe gap.
DNP Need Time 0E 11 10
From 1 to 30 in steps of 1
[Courier Number (time-minutes)]
DNP 3.0 versions only. The duration of time waited before requesting another time sync from the master.
DNP App Fragment 0E 12 2048
From 100 to 2048 in steps of 1
[Unsigned Integer (32 bits)]
DNP 3.0 versions only. The maximum message length (application fragment size) transmitted by the IED.
DNP App Timeout 0E 13 2
From 1 to 120 in steps of 1
[Courier Number (time-seconds)]
DNP 3.0 versions only. Duration of time waited, after sending a message fragment and awaiting a confirmation from the master.
DNP SBO Timeout 0E 14 10
From 1 to 10 in steps of 1
[Courier Number (time-seconds)]
DNP 3.0 versions only. Duration of time waited, after receiving a select command and awaiting an operate confirmation from the master.
DNP Link Timeout 0E 15 0
From 0 to 120 in steps of 1
[Courier Number (time-seconds)]
DNP 3.0 versions only. Duration of time that the IED will wait for a Data Link Confirm from the master. A value of 0 means data link support
disabled and 1 to 120 seconds is the timeout setting.
Class 0 Poll 0E 16 Running Counters
0 or 1
[Indexed String]
Used for DNP serial only.
When set the cell to “Running Counters”, the IED will only report the static counters (object 20) in class 0 responses. Otherwise if set to
“Frozen Counters”, the IED will only report the frozen counters (object 21) in class 0 responses.
NIC Protocol 0E 1F IEC61850
UCA 2.0
UCA 2.0 GOOSE
IEC61850
DNP3.0
[Indexed String]
IEC61850 versions only. Indicates that IEC 61850 will be used on the rear Ethernet port.
NIC Mac Address 0E 22
NIC Mac Address
[ASCII Text (17 Chars)]
IEC61850 versions only. Indicates the MAC address of the rear Ethernet port.
NIC Tunl Timeout 0E 64 5
From 1 to 30 in steps of 1
[Courier Number (time-minutes)]
IEC61850 versions only. Duration of time waited before an inactive tunnel to MiCOM S1 Studio is reset.
NIC Link Report 0E 6A Alarm
Alarm
Event
None
[Indexed String]
IEC61850 versions only.
Configures how a failed/unfitted network link (copper or fibre) is reported:
Alarm - an alarm is raised for a failed link
Event - an event is logged for a failed link
None - nothing reported for a failed link
