MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Meas Scaling 0E A6 Primary
Normalised
Primary
Secondary
[Indexed String]
DNP 3.0 over Ethernet versions only. Setting to report analogue values in terms of primary, secondary or normalized (with respect to the
CT/VT ratio setting) values.
NIC Tunl Timeout 0E A7 5
From 1 to 30 in steps of 1
[Courier Number (time-minutes)]
DNP 3.0 over Ethernet versions only. Duration of time waited before an inactive tunnel to MiCOM S1 Studio is reset.
NIC Link Report 0E A8 Alarm
Alarm
Event
None
[Indexed String]
DNP 3.0 over Ethernet versions only.
Configures how a failed/unfitted network link (copper or fibre) is reported:
Alarm - an alarm is raised for a failed link
Event - an event is logged for a failed link
None - nothing reported for a failed link
SNTP PARAMETERS
0E
AA
DNP 3.0 over Ethernet versions only
SNTP Server 1 0E AB 0.0.0.0
SNTP Server 1
[ASCII Text]
DNP 3.0 over Ethernet versions only. Indicates the SNTP Server 1 address.
SNTP Server 2 0E AC 0.0.0.0
SNTP Server 2
[ASCII Text]
DNP 3.0 over Ethernet versions only. Indicates the SNTP Server 2 address.
SNTP Poll Rate 0E AD 64
SNTP Poll Rate
[ASCII Text]
DNP 3.0 over Ethernet versions only. Duration of SNTP poll rate in seconds.
DNP Need Time 0E B1 10
From 1 to 30 in steps of 1
[Courier Number (time-minutes)]
DNP 3.0 versions only. The duration of time waited before requesting another time sync from the master.
DNP App Fragment 0E B2 2048
From 100 to 2048 in steps of 1
[Unsigned Integer (32 bits)]
DNP 3.0 versions only. The maximum message length (application fragment size) transmitted by the IED.
DNP App Timeout 0E B3 2
From 1 to 120 in steps of 1
[Courier Number (time-seconds)]
DNP 3.0 versions only. Duration of time waited, after sending a message fragment and awaiting a confirmation from the master.
DNP SBO Timeout 0E B4 10
From 1 to 10 in steps of 1
[Courier Number (time-seconds)]
DNP 3.0 versions only. Duration of time waited, after receiving a select command and awaiting an operate confirmation from the master.
Class 0 Poll 0E B5 Running Counters
0 or 1
[Indexed String]
Used for DNP3 over Ethernet only.
When set the cell to “Running Counters”, the IED will only report the static counters (object 20) in class 0 responses. Otherwise if set to
“Frozen Counters”, the IED will only report the frozen counters (object 21) in class 0 responses.
SNMP PARAMETERS
0E
C0
SNMP specific parameters heading.
SNMP Version 0E C1 V2C and V3
None
V2C
V3
V2C and V3
[Indexed String]
Selection for the main processor SNMP version interface. Selecting ‘None’ disables this SNMP interface.
Trap Dest. IP1 0E C2 0.0.0.0
From 0.0.0.0 to 223.255.255.255 in steps of 1
[Unsigned Integer (32 bits)]
Trap destination 1 IP for the main processor SNMP version interface. This is set to the SNMP manager IP address.
Setting this cell to 0.0.0.0 disables this Trap interface
Trap Dest. IP2 0E C3 0.0.0.0
From 0.0.0.0 to 223.255.255.255 in steps of 1
[Unsigned Integer (32 bits)]
