Appendix B - Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Opto Input 23 11 18 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 24 11 19 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Filter Cntl 11 60 0xFEB7FB
Opto 2 Input State
Opto 3 Input State
Opto 4 Input State
Opto 5 Input State
Opto 6 Input State
Opto 7 Input State
Opto 8 Input State
Opto 9 Input State
Opto 10 Input State
Opto 11 Input State
Opto 12 Input State
Opto 13 Input State
Opto 14 Input State
Opto 15 Input State
Opto 16 Input State
Opto 17 Input State
Opto 18 Input State
Opto 19 Input State
Opto 20 Input State
Opto 21 Input State
Opto 22 Input State
Opto 23 Input State
Opto 24 Input State
Opto 25 Input State
Opto 26 Input State
Opto 27 Input State
Opto 28 Input State
Opto 29 Input State
Opto 30 Input State
Opto 31 Input State
Opto 32 Input State
Selects each input with a pre-set filter of ½ cycle that renders the input immune to induced noise on the wiring. The number of available bits
may be 16, 24 or 32, depending on the I/O configuration.
Characteristic 11 80 Standard 60%-80%
50% - 70%
Selects the pick-up and drop-off characteristics of the opto's. Selecting the standard setting means they nominally provide a Logic 1 or On
value for Voltages ≥80% of the set lower nominal voltage and a Logic 0 or Off value for the voltages ≤60% of the set higher nominal voltage.
This column contains settings for the type of control input (32 in all)
Ctrl I/P Status 12 01
Control Input 2
Control Input 3
