P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B139
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Control Input 5
Control Input 6
Control Input 7
Control Input 8
Control Input 9
Control Input 10
Control Input 11
Control Input 12
Control Input 13
Control Input 14
Control Input 15
Control Input 16
Control Input 17
Control Input 18
Control Input 19
Control Input 20
Control Input 21
Control Input 22
Control Input 23
Control Input 24
Control Input 25
Control Input 26
Control Input 27
Control Input 28
Control Input 29
Control Input 30
Control Input 31
Control Input 32
[Binary Flag (32 bits) Indexed String]
Cell that is used to set (1) and reset (0) the selected Control Input by simply scrolling and changing the status of selected bits. This command
will be then recognized and executed in the PSL. Alternatively, each of the 32 Control input can also be set and reset using the individual
menu setting cells as follows:
Control Input 1 12 02 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 1 set/ reset.
Control Input 2 12 03 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 2 set/ reset.
Control Input 3 12 04 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 3 set/ reset.
Control Input 4 12 05 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 4 set/ reset.
Control Input 5 12 06 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 5 set/ reset.
Control Input 6 12 07 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 6 set/ reset.
