MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Setting that defines the operative mode of the InterMiCOM_3 signal.
Selecting the channel response for this bit to Blocking allows fastest signalling, whereas setting to Direct offers higher security at the
expense of speed.
Selecting the channel response for this bit to Permissive offers higher dependability
IM3 FallBackMode 16 21 Default
Default
Latched
[Indexed String]
Setting that defines the status of IM3 signal in case of heavy noise and message synchronization being lost.
If set to ‘Latching’ the last valid IM3 status will be maintained until the new valid message is received.
If set to ‘Default’, the IM3 status, pre-defined by the user in ‘IM3 DefaultValue’ cell will be set. A new valid message will replace ‘IM3
DefaultValue’, once the channel recovers.
IM3 DefaultValue 16 22 1
0 or 1
[Unsigned Integer(16 bit)]
Setting that defines the IM3 fallback status.
IM3 FrameSyncTim 16 23 1.5
From 0.01 to 1 in steps of 0.01
[Courier Number (time-seconds)]
Time delay after which ’IM3 DefaultValue’ is applied, providing that no valid message is received in the meantime.
IM4 Cmd Type 16 28 Blocking
Disabled
Direct
Blocking
[Indexed String]
Setting that defines the operative mode of the InterMiCOM_4 signal.
Selecting the channel response for this bit to Blocking allows fastest signalling, whereas setting to Direct offers higher security at the
expense of speed.
Selecting the channel response for this bit to Permissive offers higher dependability
IM4 FallBackMode 16 29 Default
Default
Latched
[Indexed String]
Setting that defines the status of IM4 signal in case of heavy noise and message synchronization being lost.
If set to ‘Latching’ the last valid IM4 status will be maintained until the new valid message is received.
If set to ‘Default’, the IM4 status, pre-defined by the user in ‘IM4 DefaultValue’ cell will be set. A new valid message will replace ‘IM4
DefaultValue’, once the channel recovers.
IM4 DefaultValue 16 2A 1
0 or 1
[Unsigned Integer(16 bit)]
Setting that defines the IM4 fallback status.
IM4 FrameSyncTim 16 2B 1.5
From 0.01 to 1 in steps of 0.01
[Courier Number (time-seconds)]
Time delay after which ’IM4 DefaultValue’ is applied, providing that no valid message is received in the meantime.
IM5 Cmd Type 16 30 Direct
Disabled
Permissive
Direct
[Indexed String]
Setting that defines the operative mode of the InterMiCOM_5 signal.
Selecting the channel response for this bit to Blocking allows fastest signalling, whereas setting to Direct offers higher security at the
expense of speed.
Selecting the channel response for this bit to Permissive offers higher dependability
IM5 FallBackMode 16 31 Default
Default
Latched
[Indexed String]
Setting that defines the status of IM5 signal in case of heavy noise and message synchronization being lost.
If set to ‘Latching’ the last valid IM5 status will be maintained until the new valid message is received.
If set to ‘Default’, the IM5 status, pre-defined by the user in ‘IM5 DefaultValue’ cell will be set. A new valid message will replace ‘IM5
DefaultValue’, once the channel recovers.
IM5 DefaultValue 16 32 0
0 or 1
[Unsigned Integer(16 bit)]
Setting that defines the IM5 fallback status.
IM5 FrameSyncTim 16 33 1.5
From 0.01 to 1 in steps of 0.01
[Courier Number (time-seconds)]
Time delay after which ‘IM5 DefaultValue’ is applied.
IM6 Cmd Type 16 38 Direct
Disabled
Permissive
