GE P54E - Page 718

Appendix B - Settings and Signals
P54A/B/C/E
B152
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Direct
[Indexed String]
Setting that defines the operative mode of the InterMiCOM_6 signal.
Selecting the channel response for this bit to Blocking allows fastest signalling, whereas setting to Direct offers higher security at the
expense of speed.
Selecting the channel response for this bit to Permissive offers higher dependability
IM6 FallBackMode 16 39 Default
Default
Latched
[Indexed String]
Setting that defines the status of IM6 signal in case of heavy noise and message synchronization being lost.
If set to ‘Latching’ the last valid IM6 status will be maintained until the new valid message is received.
If set to ‘Default’, the IM6 status, pre-defined by the user in ‘IM6 DefaultValue’ cell will be set. A new valid message will replace ‘IM6
DefaultValue’, once the channel recovers.
IM6 DefaultValue 16 3A 0
0 or 1
[Unsigned Integer(16 bit)]
Setting that defines the IM6 fallback status.
IM6 FrameSyncTim 16 3B 1.5
From 0.01 to 1 in steps of 0.01
[Courier Number (time-seconds)]
Time delay after which ‘IM6 DefaultValue’ is applied.
IM7 Cmd Type 16 40 Direct
Disabled
Permissive
Direct
[Indexed String]
Setting that defines the operative mode of the InterMiCOM_7 signal.
Selecting the channel response for this bit to Blocking allows fastest signalling, whereas setting to Direct offers higher security at the
expense of speed.
Selecting the channel response for this bit to Permissive offers higher dependability
IM7 FallBackMode 16 41 Default
Default
Latched
[Indexed String]
Setting that defines the status of IM7 signal in case of heavy noise and message synchronization being lost.
If set to ‘Latching’ the last valid IM7 status will be maintained until the new valid message is received.
If set to ‘Default’, the IM7 status, pre-defined by the user in ‘IM7 DefaultValue’ cell will be set. A new valid message will replace ‘IM7
DefaultValue’, once the channel recovers.
IM7 DefaultValue 16 42 0
0 or 1
[Unsigned Integer(16 bit)]
Setting that defines the IM7 fallback status.
IM7 FrameSyncTim 16 43 1.5
From 0.01 to 1 in steps of 0.01
[Courier Number (time-seconds)]
Time delay after which ‘IM7 DefaultValue’ is applied.
IM8 Cmd Type 16 48 Direct
Disabled
Permissive
Direct
[Indexed String]
Setting that defines the operative mode of the InterMiCOM_8 signal.
Selecting the channel response for this bit to Blocking allows fastest signalling, whereas setting to Direct offers higher security at the
expense of speed.
Selecting the channel response for this bit to Permissive offers higher dependability
IM8 FallBackMode 16 49 Default
Default
Latched
[Indexed String]
Setting that defines the status of IM8 signal in case of heavy noise and message synchronization being lost.
If set to ‘Latching’ the last valid IM8 status will be maintained until the new valid message is received.
If set to ‘Default’, the IM8 status, pre-defined by the user in ‘IM8 DefaultValue’ cell will be set. A new valid message will replace ‘IM8
DefaultValue’, once the channel recovers.
IM8 DefaultValue 16 4A 0
0 or 1
[Unsigned Integer(16 bit)]
Setting that defines the IM8 fallback status.
IM8 FrameSyncTim 16 4B 1.5
From 0.01 to 1 in steps of 0.01
[Courier Number (time-seconds)]
Time delay after which ‘IM8 DefaultValue’ is applied.
