MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
FUNCTION KEYS
17
00
This column contains the function key definitions
Fn Key Status 17 01
Fn Key Status
[Binary Flag (10 bits) Indexed String]
Displays the status of each function key.
Fn Key 1 17 02 Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
state.
Fn Key 1 Mode 17 03 Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
Fn Key 1 Label 17 04 Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 2 17 05 Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 2 Mode 17 06 Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
Fn Key 2 Label 17 07 Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 3 17 08 Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 3 Mode 17 09 Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
Fn Key 3 Label 17 0A Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 4 17 0B Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 4 Mode 17 0C Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
