MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
remain ‘high’ as long as key is pressed.
Fn Key 4 Label 17 0D Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 5 17 0E Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 5 Mode 17 0F Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
Fn Key 5 Label 17 10 Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 6 17 11 Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 6 Mode 17 12 Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
Fn Key 6 Label 17 13 Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 7 17 14 Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 7 Mode 17 15 Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
Fn Key 7 Label 17 16 Function Key 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Allows the text of the function key to be changed to something more suitable for the application.
Fn Key 8 17 17 Unlocked
Disabled
Unlocked (Enabled)
Locked
[Indexed String]
Setting to activate function key. The ‘Lock’ setting allows a function key output that is set to toggle mode to be locked in its current active
position.
Fn Key 8 Mode 17 18 Normal
Normal
Toggled
[Indexed String]
Sets the function key in toggle or normal mode. In ‘Toggle’ mode, a single key press will set/latch the function key output as ‘high’ or ‘low’ in
programmable scheme logic. This feature can be used to enable/disable IED functions. In the ‘Normal’ mode the function key output will
remain ‘high’ as long as key is pressed.
