Appendix B - Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
IEC 61850 versions only. The Publisher Sim cell allows the simulation bit to be sent in the GOOSE message, for example for testing or
commissioning.
When ‘Disabled’ is selected, the simulation bit for the goose control block is not set.
When ‘Enabled’ is selected, the simulation bit for the goose control block is set.
Once testing is complete the cell must be set back to ‘Disabled’ to restore the GOOSE scheme back to normal service.
Note: The cell ‘Test Mode’ under IED Configurator used in software prior to IEC 61850 Edition 2 has been renamed as ‘Publisher Sim’
Ignore Test Flag 19 73 No
Yes
IEC61850 versions only. The Test Mode cell allows the test pattern to be sent in the GOOSE message, for example for testing or
commissioning. When ‘Disabled’ is selected, the test flag is not set. When ‘Pass Through’ is selected, the test flag is set, but the data in the
GOOSE message is sent as normal. When ‘Forced’ is selected, the test flag is set, and the data sent in the GOOSE message is as per the ‘VOP
Test Pattern’ setting below. Once testing is complete the cell must be set back to ‘Disabled’ to restore the GOOSE scheme back to normal
This column contains settings for Current Differential/IM64 Configuration
No. of Junctions 20 70 1
3 Junctions
4 Junctions
Number Of Junction In the Power System Scheme being protected
No. of Junctions 20 70 1
3 Junctions
4 Junctions
[Indexed String]
Number Of Junction In the Power System Scheme being protected
No. of Terminals 20 71 2 Terminal
3 Terminals
4 Terminals
5 Terminals
6 Terminals
Number of Terminal (IEDs) being used
No. of Terminals 20 71 2 Terminal
3 Terminals
4 Terminals
5 Terminals
6 Terminals
Communication Address for each of the IEDs in the scheme. Each letter is the IED address within a scheme.
Scheme Address 20 72 1
From 1 to 16 in steps of 1
[Indexed String]
Communication Address for each of the IEDs in the scheme. The number is the scheme number.
Terminal Address 20 73 A
From 0 to 5 in steps of 1
[Indexed String]
Terminal Address 20 73 A
Terminal Address for P541 only
Clock Source Ch1 20 74 Internal
External
[Indexed String]
Setting that defines which clock source is used to synchronize data transmissions over channel 1. The setting will depend on
communications configuration and external clock source availability. If IED's are connected direct fibre over channel 1, ‘Internal’ setting
should be selected. If channel 1 is routed via a multiplexer, either setting may be required (see Application Notes).
Clock Source Ch2 20 75 Internal
External
Setting that defines which clock source is used to synchronize data transmissions over channel 2. The setting will depend on
communications configuration and external clock source availability. If IED's are connected direct fibre over channel 2, ‘Internal’ setting
should be selected. If channel 2 is routed via a multiplexer, either setting may be required (see Application Notes).
