Appendix B - Settings and Signals
P54A/B/C/E
B156
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
only be set using the .MCL file.
This setting allows for an Ethernet connection to be established with the relay without needing to first send a .MCL file via the serial port.
Once a connection has been established the correct .MCL can be sent via Ethernet and this setting can be changed back to “Disabled”.
Note: You can enable this feature when you use the IED for the first time. However, the IED will at this point not have an active MCL file and
any data model extracted from IEC 61850 may not be correct. Therefore, to prevent any issues you should send a correct MCL file to the IED
after a
connection is first established.
IP PARAMETERS
19
30
IEC61850 versions only.
IP address 19 31
IP address
[ASCII text]
IEC61850 versions only. Displays the unique network IP address that identifies the IED.
Subnet mask 19 32
Subnet mask
[ASCII text]
IEC61850 versions only. Displays the sub-network the IED is connected to.
Gateway 19 33
Gateway
[ASCII text]
IEC61850 versions only. Displays the IP address of the gateway (proxy) that the IED is connected to, if any.
Media 19 34 1xFibre Optic
0 or 1
[Indexed String]
IEC 61850 versions only. Displays the communication media of the Ethernet port that is currently in use.
IP address 19 38 0.0.0.0
IP address
[ASCII text]
IEC 61850 versions only. When IP From HMI is enabled this is used to set the unique network IP address that identifies the unit.
Subnet mask 19 39 0.0.0.0
Subnet mask
[ASCII text]
IEC 61850 versions only. When IP From HMI is enabled this is used to set the sub-network mask.
Gateway 19 3A 0.0.0.0
Gateway
[ASCII text]
IEC61850 versions only. Set the IP address of the gateway (proxy) the relay is connected to via HMI if any.
Media 19 3B 1xFibre Optic
0 or 1
[Indexed String]
IEC 61850 versions only. Sets the communication media of the Ethernet port. For products with dual redundant fibre select the
1xCopper/2xFibre setting
SNTP PARAMETERS
19
40
IEC61850 versions only.
SNTP Server 1 19 41
SNTP Server 1
[ASCII text]
IEC61850 versions only. Displays the IP address of the primary SNTP server.
SNTP Server 2 19 42
SNTP Server 2
[ASCII text]
IEC61850 versions only. Displays the IP address of the secondary SNTP server.
IEC 61850 SCL
19
50
IEC61850 versions only.
IED Name 19 51
IED Name
[ASCII text]
IEC61850 versions only. 8 character IED name, which is the unique name on the IEC 61850 network for the IED, usually taken from the SCL
file.
IEC 61850 GOOSE
19
60
IEC61850 versions only.
GoEna 19 70 0x00000000
Disabled
Enabled
[Binary Flag (32)]
IEC61850 versions only. Setting to enable GOOSE publisher settings.
Publisher Sim 19 71 0x00000000
Disabled
Pass Through
Forced
[Binary Flag (32) Indexed String]
