P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B167
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
T6 J3
T1 J4
T2 J4
T3 J4
T4 J4
T5 J4
T6 J4
[Binary Flag (24) & Indexed String]
A map of the terminals and junctions in the system for P541 only
Length Local 30 22 45000
From 100 to 10000000 in steps of 10
[Courier Number (metres)]
Length of the local terminal section in KM
Length Local 30 23 28000
From 0.06 to 621 in steps of 0.005
[Courier Number (miles)]
Length of the local terminal section in miles
Length J1-J2 30 24 100000
From 100 to 10000000 in steps of 10
[Courier Number (metres)]
Distance between junction 1 and 2 when it is a mult-junction network in KM
Length J1-J2 30 25 62.1
From 0.06 to 621 in steps of 0.005
[Courier Number (miles)]
Distance between junction 1 and 2 when it is a mult-junction network in KM
Length J2-J3 30 26 100000
From 100 to 10000000 in steps of 10
[Courier Number (metres)]
Distance between junction 2 and 3 when it is a multi-junction network in KM
Length J2-J3 30 27 62.1
From 0.06 to 621 in steps of 0.005
[Courier Number (miles)]
Distance between junction 2 and 3 when it is a multi-junction network in KM
Length J3-J4 30 28 100000
From 100 to 10000000 in steps of 10
[Courier Number (metres)]
Distance between junctions 3 and 4 when it is a multi-junction network in KM
Length J3-J4 30 29 62.1
From 0.06 to 621 in steps of 0.005
[Courier Number (miles)]
Distance between junctions 3 and 4 when it is a multi-junction network in KM
Line Type Local 30 2A UnderGndCable
OverheadLine
[Indexed String]
This setting is used to select the overhead line or the underground cable. If it is overhead line, the admittance parameters will be invisiable,
they will be deduced via fomular
Z1Local 30 2B 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Positive sequence impedance amplitude of the local section length per KM
Z1LocalAngle 30 2C 70
From 0 to 10 in steps of 0.01
[Courier Number (angle)]
Positive Sequence impedance angle of the local section length
Z0Local 30 2D 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Zero Sequence impedance amplitude of the local section length
Z0LocalAngle 30 2E 70
From 0 to 10 in steps of 1
[Courier Number (angle)]
Zero Sequence impedance angle of the local section length
Y1Local 30 2F 0.00000001*I1
From 0.00000001*I1 to 10*I1 in steps of
0.00000001*I1
[Courier Number (inverse ohms)]
Positive sequence admittance amplitude of the local section length (the conductance is neglected)
Y0Local 30 30 0.00000001*I1
From 0.00000001*I1 to 10*I1 in steps of
0.00000001*I1
[Courier Number (inverse ohms)]
Zero sequence admittance amplitude of the local section length (the conductance is neglected)
Line Type J1-J2 30 31 UnderGndCable
OverheadLine
[Indexed String]
This setting is used to select the overhead line or the underground cable. If it is overhead line, the admittance parameters will be invisiable,
