Appendix B - Settings and Signals
P54A/B/C/E
B168
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
they will be deduced via fomular
Z1 J1-J2 30 32 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Positive sequence impedance amplitude between J1 and J2
Z1 angle J1-J2 30 33 70
From 0 to 10 in steps of 0.1
[Courier Number (angle)]
Positive sequence impedance amplitude of the section between J1 and J2
Z0 J1-J2 30 34 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Zero sequence impedance amplitude of the section between J1 and J2
Z0 angle J1-J2 30 35 70
From 0 to 10 in steps of 0.1
[Courier Number (angle)]
Zero sequence impedance angle of the section between J1 and J2
Y1 J1-J2 30 36 0.00000001*I1
From 0.00000001*I1 to 10*I1 in steps of
0.00000001*I1
[Courier Number (inverse ohms)]
Positive sequence admittance amplitude of the section between junction J2 and J3
Y0 J1-J2 30 37 0.00000001*I1
From 0.00000001*I1 to 10*I1 in steps of
0.00000001*I1
[Courier Number (inverse ohms)]
Zero sequence admittance amplitude of the section between junction J2 and J3
Line Type J2-J3 30 38 UnderGndCable
OverheadLine
[Indexed String]
This setting is used to select the overhead line or the underground cable. If it is overhead line, the admittance parameters will be invisiable,
they will be deduced via fomular
Z1 J2-J3 30 39 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Positive sequence impedance amplitude of the section between J2 and J3
Z1 angle J2-J3 30 3A 70
From 0 to 10 in steps of 0.1
[Courier Number (angle)]
Positive sequence impedance angle of the section between J2 and J3
Z0 J2-J3 30 3B 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Zero sequence impedance amplitude of the section between J2 and J3
Z0 angle J2-J3 30 3C 70
From 0 to 10 in steps of 0.1
[Courier Number (angle)]
Zero sequence impedance angle of the section between J2 and J3
Y1 J2-J3 30 3D 0.00000001*I1
From 0.00000001*I1 to 10*I1 in steps of
0.00000001*I1
[Courier Number (inverse ohms)]
Positive sequence admittance amplitude of the section between junction J2 and J3
Y0 J2-J3 30 3E 0.00000001*I1
From 0.00000001*I1 to 10*I1 in steps of
0.00000001*I1
[Courier Number (inverse ohms)]
Zero sequence admittance amplitude of the section between junction J2 and J3
Line Type J3-J4 30 3F UnderGndCable
OverheadLine
[Indexed String]
This setting is used to select the overhead line or the underground cable. If it is overhead line, the admittance parameters will be invisiable,
they will be deduced via fomular
Z1 J3-J4 30 40 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Positive sequence impedance amplitude of the section J3 and J4
Z1 angle J3-J4 30 41 70
From 0 to 10 in steps of 0.1
[Courier Number (angle)]
Positive sequence impedance angle of the section between J3 and J4
Z0 J3-J4 30 42 8
From 0.05*v1/I1 to 500*V1/I1 in steps of 0.01*V1/I1
[Courier Number (impedance)]
Zero sequence impedance amplitude of the section between J3 and J4
Z0 angle J3-J4 30 43 70
From 0 to 10 in steps of 0.1
[Courier Number (angle)]
