GE P54E - GROUP 1: SEFREF PROTN

Appendix B - Settings and Signals
P54A/B/C/E
B180
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Neg Sequence
[Indexed String]
Setting that determines whether the directional function uses zero sequence or negative sequence voltage polarizing.
IN> VNpol Input 38 58 Derived
Measured
Derived
[Indexed String]
Setting determines which will be selected as the input source of polarizing voltage for directional decision, 'derived' or 'measured'.
IN> VNpol Set 38 59 1
From 0.5*V1 to 80*V1 in steps of 0.5*V1
[Courier Number (voltage)]
Setting for the minimum zero sequence voltage polarizing quantity for directional decision. Setting is visible only when ‘Zero Sequence’
polarization is set.
IN> V2pol Set 38 5A 1
From 0.5*V1 to 25*V1 in steps of 0.5*V1
[Courier Number (voltage)]
Setting for the minimum negative sequence voltage polarizing quantity for directional decision. Setting is visible only when ‘Negative
Sequence’ polarization is set.
IN> I2pol Set 38 5B 0.08
From 0.08*I1 to 1.0*I1 in steps of 0.01*I1
[Courier Number (current)]
Setting for the minimum negative sequence current polarizing quantity for directional decision. Setting is visible only when ‘Negative
Sequence’ polarization is set.
IN>1 Usr RstChar 38 60 DT
DT
Default Curve 1
Default Curve 2
Default Curve 3
Default Curve 4
[Indexed String]
Setting to determine the type of reset/release characteristic of the user defined curves.
DEF REV Set 39 08 0.04
From 0.03*I1 to 1.0*I1 in steps of 0.01*I1
[Courier Number (current)]
Setting the reverse pickup current sensitivity for residual current (= 3.Io).
Virtual I Pol 39 09 Enabled
Disabled
Enabled
[Indexed String]
To enable (activate) or disable (turn off) the Virtual Current Polarizing if it has been armed by the DEF Polarizing setting The setting is invisible
if ‘Neg. Sequence’ polarization is set.
GROUP 1: SEF/REF
PROT'N
3A 00
This column contains settings for SEF/REF
SEF/REF Options 3A 01 SEF Enabled
SEF Enabled
Wattmetric SEF
Hi Z REF
[Indexed String]
Setting to select the type of sensitive earth fault protection function and the type of high-impedance function to be used.
ISEF>1 Function 3A 2A DT
Disabled
DT
IEC S Inverse
IEC V Inverse
IEC E Inverse
UK LT Inverse
IEEE M Inverse
IEEE V Inverse
IEEE E Inverse
US Inverse
US ST Inverse
IDG
Default Curve 1
Default Curve 2
Default Curve 3
Default Curve 4
[Indexed String]
Setting for the tripping characteristic for the first stage sensitive earth fault element.
ISEF>1 Direction
3A
2B
Non-Directional
Non-Directional
