Appendix B - Settings and Signals
P54A/B/C/E
B186
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
V>1 TMS 42 13 1
From 0.5 to 100 in steps of 0.5
[Courier Number (decimal)]
Setting for the time multiplier setting to adjust the operating time of the IDMT characteristic.
V>2 Status 42 14 Disabled
Disabled
Enabled
[Indexed String]
Setting to enable or disable the second stage overvoltage element.
V>2 Voltage Set 42 15 150
From 60*V1 to 185*V1 in steps of 1*V1
[Courier Number (voltage)]
This setting determines the pick-up setting for the second stage overvoltage element.
V>2 Time Delay 42 16 0.5
From 0 to 100 in steps of 0.01
[Courier Number (time-seconds)]
Setting for the operating time-delay for the second stage definite time overvoltage element.
COMP OVERVOLTAGE
42
20
Compensated Over Voltage Sub Heading
V1>1 Cmp Funct 42 23 Disabled
Disabled
DT
IDMT
[Indexed String]
Tripping characteristic setting for the first stage compensated overvoltage element.
V1>1 Cmp Vlt Set 42 24 75
From 60*V1 to 110*V1 in steps of 1*V1
[Courier Number (voltage)]
Sets the pick-up setting for first stage overvoltage element. This is set in terms of the phase to neutral voltage.
V1>1 Cmp Tim Dly 42 25 10
From 0 to 100 in steps of 0.01
[Courier Number (time-seconds)]
Setting for the operating time-delay for the first stage definite time compensated overvoltage element.
V1>1 Cmp TMS 42 26 1
From 0.5 to 100 in steps of 0.5
[Courier Number (decimal)]
Setting for the time multiplier setting to adjust the operating time of the IDMT characteristic.
V1>2 Cmp Status 42 27 Disabled
Disabled
Enabled
[Indexed String]
Setting to enable or disable the second stage compensated overvoltage element.
V1>2 Cmp Vlt Set 42 28 85
From 60*V1 to 110*V1 in steps of 1*V1
[Courier Number (voltage)]
This setting determines the pick-up setting for the second stage overvoltage element.
V1>2 Cmp Tim Dly 42 29 0.5
From 0 to 100 in steps of 0.01
[Courier Number (time-seconds)]
Setting for the operating time-delay for the second stage definite time compensated overvoltage element.
GROUP 1: FREQ
PROTECTION
43 00
This column contains settings for Frequency
UNDER FREQUENCY
43
01
Under frequency Sub Heading
F<1 Status 43 02 Enabled
Disabled
Enabled
[Indexed String]
Setting to enable or disable the first stage underfrequency element.
F<1 Setting 43 03 49.5
From 45 to 65 in steps of 0.01
[Courier Number (frequency)]
Setting that determines the pick-up threshold for the first stage underfrequency element.
F<1 Time Delay 43 04 4
From 0 to 100 in steps of 0.01
[Courier Number (time-seconds)]
Setting that determines the minimum operating time-delay for the first stage underfrequency element.
F<2 Status 43 05 Disabled
Disabled
Enabled
[Indexed String]
Setting to enable or disable the second stage underfrequency element.
F<2 Setting 43 06 49
From 45 to 65 in steps of 0.01
[Courier Number (frequency)]
