P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B199
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
SP AR Dead Time 49 67 0.5
From 0 to 10 in steps of 0.01
[Courier Number (time-seconds)]
Dead time setting for single phase auto-reclose.
3P AR DT Shot 1 49 68 0.3
From 0.01 to 300 in steps of 0.01
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (first shot).
3P AR DT Shot 1 49 68 0.3
From 0.01 to 300 in steps of 0.01
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (first shot).
3P AR DT Shot 2 49 69 60
From 1 to 9999 in steps of 1
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (2nd shot).
3P AR DT Shot 2 49 69 60
From 1 to 9999 in steps of 1
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (2nd shot).
3P AR DT Shot 3 49 6A 60
From 1 to 9999 in steps of 1
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (3rd shot).
3P AR DT Shot 3 49 6A 60
From 1 to 9999 in steps of 1
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (3rd shot).
3P AR DT Shot 4 49 6B 60
From 1 to 9999 in steps of 1
[Courier Number (time-seconds)]
Dead time setting for three phase auto-reclose (4th shot).
Follower Time 49 6C 5
From 0.1 to 300 in steps of 0.01
[Courier Number (time-seconds)]
Time delay setting for follower CB reclosing after leader CB has reclosed.
SPAR ReclaimTime 49 6D 60
From 1 to 600 in steps of 1
[Courier Number (time-seconds)]
Reclaim time setting following single phase auto-reclosure.
SPAR ReclaimTime 49 6D 60
From 1 to 600 in steps of 1
[Courier Number (time-seconds)]
Reclaim time setting following single phase auto-reclosure.
3PAR ReclaimTime 49 6E 180
From 1 to 600 in steps of 1
[Courier Number (time-seconds)]
Reclaim time setting following three phase auto-reclosure.
3PAR ReclaimTime 49 6E 180
From 1 to 600 in steps of 1
[Courier Number (time-seconds)]
Reclaim time setting following three phase auto-reclosure.
3PAR ReclaimTime 49 6E 180
From 1 to 600 in steps of 1
[Courier Number (time-seconds)]
Reclaim time setting following three phase auto-reclosure.
AR CBHealthyTime 49 6F 5
From 0.01 to 9999 in steps of 0.01
[Courier Number (time-seconds)]
Settable time delay for autoreclosure with this circuit breaker check. If the circuit breaker does not indicate a healthy condition in this time
period following an auto close command then the IED will lockout and alarm. CB Healthy is required for manual and auto reclosures.
Z1 AR 49 72 Initiate AR
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of instantaneous zone 1 on AR operation. Set Initiate AR if the trip should initiate a cycle, and Block AR if an
instantaneous zone 1 trip should cause lockout. (Only in models with distance option)
Phase Comp AR 49 73 Initiate AR
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the phase comparison tripping on AR operation.
Dist Aided AR 49 74 Initiate AR
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the aided distance schemes tripping on AR operation.
(Only in models with distance option)
