MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Dir Aided AR 49 7A Block AR
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of aided Directional Comparison protection (DEF) on AR operation.
(Only in models with distance option)
TOR AR 49 7B Block AR
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of Trip On Reclose (TOR) on AR operation.
(Only in models with distance option)
I>1 AR 49 7C No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of first stage overcurrent protection on AR operation. Set Initiate AR if the trip should initiate a cycle, and
Block AR if trip should cause lockout. Set No action if trip should exert no specific logic control on the recloser.
(Only in models with distance option)
I>2 AR 49 7D No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the second stage overcurrent protection on AR operation.
I>3 AR 49 7E No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the third stage overcurrent protection on AR operation.
I>4 AR 49 7F No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the fourth stage overcurrent protection on AR operation.
IN>1 AR 49 80 No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the first stage earth fault overcurrent protection on AR operation.
IN>2 AR 49 81 No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the second stage earth fault overcurrent protection on AR operation.
IN>3 AR 49 82 No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the third stage earth fault overcurrent protection on AR operation.
IN>4 AR 49 83 No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the fourth stage earth fault overcurrent protection on AR operation.
ISEF>1 AR 49 84 No Action
No Action
Initiate AR
Block AR
[Indexed String]
Setting that determines impact of the first stage sensitive earth fault overcurrent protection on AR operation.
ISEF>2 AR 49 85 No Action
No Action
Initiate AR
Block AR
[Indexed String]
