Appendix B - Settings and Signals
P54A/B/C/E
B202
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
This setting enables CB1 to auto-reclose as leader when the system satisfies all the System Check Synchronism Stage 1 criteria as defined
under CB1 CS1 Status settings in the SYSTEM CHECKS column.
CB SC CS2 49 AA Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to auto-reclose as leader when the system satisfies all the System Check Synchronism Stage 2 criteria as defined
under the setting CB CS2 Status in the SYSTEM CHECKS column.
CB1L SC CS2 49 AA Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to auto-reclose as leader when the system satisfies all the System Check Synchronism Stage 2 criteria as defined
under the setting CB1 CS2 status in the SYSTEM CHECKS column.
CB SC DLLB 49 AB Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to auto-reclose as leader when the dead line & live bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB1L SC DLLB 49 AB Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to auto-reclose as leader when the dead line & live bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB SC LLDB 49 AC Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to auto-reclose as leader when the live line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB1L SC LLDB 49 AC Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to auto-reclose as leader when the live line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB SC DLDB 49 AD Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to auto-reclose as leader when the dead line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB1L SC DLDB 49 AD Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to auto-reclose as leader when the dead line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB2L SC all 49 AE Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to auto-reclose as leader when the dead line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
GROUP 1: INPUT
LABELS
4A 00
This column contains settings for Input Labels
Opto Input 1 4A 01 Input L1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for Opto Input 1
Opto Input 2 4A 02 Input L2
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for Opto Input 2
Opto Input 3 4A 03 Input L3
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for Opto Input 3
Opto Input 4
4A
04
Input L4
From 32 to 163 in steps of 1
