P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B205
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Label for output relay 17
Relay 18 4B 12 Output R18
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 18
Relay 19 4B 13 Output R19
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 19
Relay 20 4B 14 Output R20
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 20
Relay 21 4B 15 Output R21
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 21
Relay 22 4B 16 Output R22
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 22
Relay 23 4B 17 Output R23
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 23
Relay 24 4B 18 Output R24
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 24
Relay 25 4B 19 Output R25
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 25
Relay 26 4B 1A Output R26
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Label for output relay 26
Select Record B0 01
From 0 to 65535 in steps of 1
[Unsigned Integer(2)]
Faulted Phase B0 07
Faulted Phase
[Binary Flag (8) Indexed String]
Start Elements 1 B0 08
1 bit per elementLSB
String..MSB String
Start Elements 1
[Binary Flag (32)Indexed String]
Start Elements 2 B0 09
1 bit per elementLSB
String..MSB String
Start Elements 2
[Binary Flag (32)Indexed String]
Trip Elements(1) B0 0A
1 bit per elementLSB
String..MSB String
Trip Elements(1)
[Binary Flag (32)Indexed String]
Trip Elements(2) B0 0B
1 bit per elementLSB
String..MSB String
Trip Elements(2)
[Binary Flag (32)Indexed String]
Fault Alarms B0 0C
1 bit per elementLSB
String..MSB String
Fault Alarms
[Binary Flag (32)Indexed String]
Fault Time B0 0D
Fault Time
[IEC870 Time & Date]
Active Group B0 0E
Active Group
[Unsigned Integer]
System Frequency B0 0F
System Frequency
[Courier Number (frequency)]
Fault Duration
B0
10
Fault Duration
