Appendix B - Settings and Signals
P54A/B/C/E
B206
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
[Courier Number (time-seconds)]
CB Operate Time B0 11
CB Operate Time
[Courier Number (time-seconds)]
Relay Trip Time B0 12
Relay Trip Time
[Courier Number (time-seconds)]
Fault Location B0 13
Fault Location
[Courier Number (metres)]
Fault Location B0 14
Fault Location
[Courier Number (miles)]
Fault Location B0 15
Fault Location
[Courier Number (impedance)]
Fault Location B0 16
Fault Location
[Courier Number (percentage)]
CB2 Operate Time B0 17
CB2 Operate Time
[Courier Number (time-seconds)]
IA Pre Flt B0 20
IA Pre Flt
[Courier Number (current)]
IA Angle Pre Flt B0 21
IA Angle Pre Flt
[Courier Number (degrees)]
IB Pre Flt B0 22
IB Pre Flt
[Courier Number (current)]
IB Angle Pre Flt B0 23
IB Angle Pre Flt
[Courier Number (degrees)]
IC Pre Flt B0 24
IC Pre Flt
[Courier Number (current)]
IC Angle Pre Flt B0 25
IC Angle Pre Flt
[Courier Number (degrees)]
IN Pre Flt B0 26
IN Pre Flt
[Courier Number (current)]
IN Angle Pre Flt B0 27
IN Angle Pre Flt
[Courier Number (degrees)]
IM Pre Flt B0 28
IM Pre Flt
[Courier Number (current)]
IM Angle Pre Flt B0 29
IM Angle Pre Flt
[Courier Number (degrees)]
VA Pre Flt B0 30
VA Pre Flt
[Courier Number (voltage)]
VA Angle Pre Flt B0 31
VA Angle Pre Flt
[Courier Number (degrees)]
