P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B209
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
[Courier Number (time-seconds)]
Ch 2 Prop Delay B0 74
Ch 2 Prop Delay
[Courier Number (time-seconds)]
Started Elements B0 90
1 bit per elementLSB
String..MSB String
Started Elements
[Binary Flag (32)Indexed String]
Started Elements 2 B0 91
1 bit per elementLSB
String..MSB String
Started Elements 2
[Binary Flag (32)Indexed String]
Started Elements 3 B0 92
1 bit per elementLSB
String..MSB String
Started Elements 3
[Binary Flag (32)Indexed String]
Tripped Elements (1) B0 94
1 bit per elementLSB
String..MSB String
Tripped Elements (1)
[Binary Flag (32)Indexed String]
Tripped Elements (2) B0 95
1 bit per elementLSB
String..MSB String
Tripped Elements (2)
[Binary Flag (32)Indexed String]
Tripped Elements (3) B0 96
1 bit per elementLSB
String..MSB String
Tripped Elements (3)
[Binary Flag (32)Indexed String]
V1 Rem Magnitude B0 98
V1 Rem Magnitude
[Courier Number (current)]
V1 Rem Phase Ang B0 99
V1 Rem Phase Ang
[Courier Number (current)]
Fault IA Local B0 A0
Fault IA Local
[Courier Number (current)]
Fault IB Local B0 A1
Fault IB Local
[Courier Number (current)]
Fault IC Local B0 A2
Fault IC Local
[Courier Number (current)]
Fault IA rem 1 B0 A3
Fault IA rem 1
[Courier Number (current)]
Fault IB rem 1 B0 A4
Fault IB rem 1
[Courier Number (current)]
Fault IC rem 1 B0 A5
Fault IC rem 1
[Courier Number (current)]
Fault IA rem 2 B0 A6
Fault IA rem 2
[Courier Number (current)]
Fault IB rem 2 B0 A7
Fault IB rem 2
[Courier Number (current)]
Fault IC rem 2 B0 A8
Fault IC rem 2
[Courier Number (current)]
Fault IA Diff B0 A9
Fault IA Diff
[Courier Number (current)]
