Appendix B - Settings and Signals
P54A/B/C/E
B210
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Fault IB Diff B0 AA
Fault IB Diff
[Courier Number (current)]
Fault IC Diff B0 AB
Fault IC Diff
[Courier Number (current)]
Fault IA Bias B0 AC
Fault IA Bias
[Courier Number (current)]
Fault IB Bias B0 AD
Fault IB Bias
[Courier Number (current)]
Fault IC Bias B0 AE
Fault IC Bias
[Courier Number (current)]
Select Record B1 01
From 0 to 65535 in steps of 1
[Unsigned Integer (16 bits)]
Time & Date B1 02
Time & Date
[IEC Date and Time]
Event Text B1 03
Event Text
[ASCII Text]
Maint Type B1 04
Maint Type
[UINT32]
Maint Data B1 05
Maint Data
[UINT32]
Domain B2 04 PSL Settings
0 or 1
[Indexed String]
Sub-Domain B2 08 Group 1
From 0 to 3 in steps of 1
[Indexed String]
Version B2 0C 256
From 0 to 65535 in steps of 1
[Unsigned Integer (2 Bytes)]
Transfer Mode B2 1C 6
Prepare Rx
Complete Rx
Prepare Tx
Complete Tx
Rx Prepared
Tx Prepared
OK
Error
[Unsigned Integer Indexed String]
Select Record B4 01 0
From -199 to 199 in steps of 1
[Unsigned Integer]
Trigger Time B4 02
Trigger Time
[IEC870 Time & Date]
Active Channels B4 03
Active Channels
[Binary Flag]
Channel Types B4 04
Channel Types
[Binary Flag]
