MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Channel Offsets B4 05
Channel Offsets
[Courier Number (decimal)]
Channel Scaling B4 06
Channel Scaling
[Courier Number (decimal)]
Channel SkewVal B4 07
Channel SkewVal
[Integer]
Channel MinVal B4 08
Channel MinVal
[Integer]
Channel MaxVal B4 09
Channel MaxVal
[Integer]
Format B4 0A
Format
[Unsigned Integer]
Upload B4 0B
Upload
[Unsigned Integer]
No. Of Samples B4 10
No. Of Samples
[Unsigned Integer]
Trig Position B4 11
Trig Position
[Unsigned Integer]
Time Base B4 12
Time Base
[Courier Number (time-seconds)]
Sample Times B4 14
Sample Times
[Unsigned Integer]
Dist. Channel 1 B4 20
Dist. Channel 1
[Integer]
Dist. Channel 2 B4 21
Dist. Channel 2
[Integer]
Dist. Channel 3 B4 22
Dist. Channel 3
[Integer]
Dist. Channel 4 B4 23
Dist. Channel 4
[Integer]
Dist. Channel 5 B4 24
Dist. Channel 5
[Integer]
Dist. Channel 6 B4 25
Dist. Channel 6
[Integer]
Dist. Channel 7 B4 26
Dist. Channel 7
[Integer]
Dist. Channel 8 B4 27
Dist. Channel 8
[Integer]
Dist. Channel 9
B4
28
Dist. Channel 9
