Appendix B - Settings and Signals
P54A/B/C/E
B212
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
[Integer]
Dist. Channel 10 B4 29
Dist. Channel 10
[Integer]
Dist. Channel 11 B4 2A
Dist. Channel 11
[Integer]
Dist. Channel 12 B4 2B
Dist. Channel 12
[Integer]
Dist. Channel 13 B4 2C
Dist. Channel 13
[Integer]
Dist. Channel 31 B4 3D
Dist. Channel 31
[Binary Flag]
Dist. Channel 32 B4 3E
Dist. Channel 32
[Binary Flag]
PSL DATA
B7
00
Grp1 PSL Ref B7 01
Grp1 PSL Ref
[ASCII Text (32 chars)]
User settable PSL reference during PSL file download
Date/Time B7 02
Date/Time
[IEC870 Date & Time]
Date and Time of when PSL file was downloaded or when firmware was downloaded/default settings restored
Grp1 PSL ID B7 03
Grp1 PSL ID
[Unsigned Integer (32 bits)]
CRC of Group 1 PSL file
Grp2 PSL Ref B7 11
Grp2 PSL Ref
[ASCII Text (32 chars)]
User settable PSL reference during PSL file download
Date/Time B7 12
Date/Time
[IEC870 Date & Time]
Date and Time of when PSL file was downloaded or when firmware was downloaded/default settings restored
Grp2 PSL ID B7 13
Grp2 PSL ID
[Unsigned Integer (32 bits)]
CRC of Group 2 PSL file
Grp3 PSL Ref B7 21
Grp3 PSL Ref
[ASCII Text (32 chars)]
User settable PSL reference during PSL file download
Date/Time B7 22
Date/Time
[IEC870 Date & Time]
Date and Time of when PSL file was downloaded or when firmware was downloaded/default settings restored
Grp3 PSL ID B7 23
Grp3 PSL ID
[Unsigned Integer (32 bits)]
CRC of Group 3 PSL file
Grp4 PSL Ref B7 31
Grp4 PSL Ref
[ASCII Text (32 chars)]
User settable PSL reference during PSL file download
Date/Time B7 32
Date/Time
[IEC870 Date & Time]
Date and Time of when PSL file was downloaded or when firmware was downloaded/default settings restored
Grp4 PSL ID B7 33
Grp4 PSL ID
[Unsigned Integer (32 bits)]
CRC of Group 4 PSL file
USER CURVES DATA
B8
00
