P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B213
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
This column contains settings for User Curve Data
Curve 1 Name B8 01 Default Curve 1
Curve 1 Name
[ASCII Text (32 chars)]
Name entered when curve downloaded
Time & Date B8 02
Time & Date
[IEC870 Date & Time]
Date and Time of when curve was downloaded or when firmware was downloaded/default settings restored
Curve 1 ID B8 03
Curve 1 ID
[Unsigned Integer 16 bits)]
CRC of curve 1
UserCurve 1 Type B8 04 Operate 1.0
Operate 1.0
Reset 1.1
[Indexed String]
Defines the user curve template, either operate or reset
Curve 2 Name B8 11 Default Curve 2
Curve 2 Name
[ASCII Text (32 chars)]
Name entered when curve downloaded
Time & Date B8 12
Time & Date
[IEC870 Date & Time]
Date and Time of when curve was downloaded or when firmware was downloaded/default settings restored
Curve 2 ID B8 13
Curve 2 ID
[Unsigned Integer (32 bits)]
CRC of curve 2
UserCurve 2 Type B8 14 Operate 1.0
Operate 1.0
Reset 1.1
[Indexed String]
Defines the user curve template, either operate or reset
Curve 3 Name B8 21 Default Curve 3
Curve 3 Name
[ASCII Text (32 chars)]
Name entered when curve downloaded
Time & Date B8 22
Time & Date
[IEC870 Date & Time]
Date and Time of when curve was downloaded or when firmware was downloaded/default settings restored
Curve 3 ID B8 23
Curve 3 ID
[Unsigned Integer (32 bits)]
CRC of curve 3
UserCurve 3 Type B8 24 Reset 1.1
Operate 1.0
Reset 1.1
[Indexed String]
Defines the user curve template, either operate or reset
Curve 4 Name B8 31 Default Curve 4
Curve 4 Name
[ASCII Text (32 chars)]
Name entered when curve downloaded
Time & Date B8 32
Time & Date
[IEC870 Date & Time]
Date and Time of when curve was downloaded or when firmware was downloaded/default settings restored
Curve 4 ID B8 33
Curve 4 ID
[Unsigned Integer (32 bits)]
CRC of curve 4
UserCurve 4 Type B8 34 Reset 1.1
Operate 1.0
Reset 1.1
[Indexed String]
Defines the user curve template, either operate or reset
Restore Def Crv B8 F0
No Operation
Default Curve 1
Default Curve 2
Default Curve 3
Default Curve 4
[Indexed String]
