Appendix B - Settings and Signals
P54A/B/C/E
B214
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Record Cntl Ref BF 01 B300
Record Cntl Ref
[Menu Cell(2)]
Record Ext Ref BF 02 B400
Record Ext Ref
[Menu Cell(2)]
Setting Transfer
BF
03
Reset Demand BF 04
Reset Demand
[None (Reset Menu Cell)]
Block Xfer Ref BF 06 B200
Block Xfer Ref
[Menu Cell(2)]
Read Only Mode BF 07
Read Only Mode
[Unsigned Integer (16)]
Encryption Key BF 10
8 registers for reading 16 character encryption key
Each register contains a pair of characters
Each register is formatted as follows:-
first character of a pair
second character of a pair
Each character is in the Courier range 33 - 122
[ASCII Text (16)]
Connected i/face BF 11
Connected i/face
[Integer]
Security Column BF 12 2500
Security Column
[Menu Cell(2)]
Port Disable BF 13 2505
Port Disable
[Menu Cell(2)]
Port Disable end BF 14 250B
Port Disable end
[Menu Cell(2)]
PW Entry Needed BF 15
PW Entry Needed
[Unsigned Integer (32 bits)]
Faulted Phase FF 07
Start A
Start B
Start C
Start N
Trip A
Trip B
Trip C
Trip N
[Binary Flag (8)]
Displays the faulted phase. Started phases + tripped phases
Start Elements 1 FF 08
General Start
Start I Diff
Start Z1
Start Z2
Start Z3
Start ZP
Start Z4
Start I>1
Start I>2
Start I>3
Start I>4
