P54A/B/C/E

Appendix B - Settings and Signals

P54xMED-TM-EN-1

B215

MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS

DESCRIPTION

Start IN1>1

Start IN1>2

Start IN1>3

Start IN1>4

Start ISEF>1

Start ISEF>2

Start ISEF>3

Start ISEF>4

Thermal Alarm

Start NVD 1

Start NVD 2

Start I2>1

Start I2>2

Start I2>3

Start I2>4

Start F<1

Start F<2

Start F<3

Start F<4

Start F>1

Start F>2

[Binary Flag (32) Indexed String]

Displays the status of the first 32 start signals.

Start Elements 2 FF 09

Start V<1

Start V<2

Start V<A

Start V<B

Start V<C

Start V>1

Start V>2

Start V>A

Start V>B

Start V>C

Start df/dt>1

Start df/dt>2

Start df/dt>3

Start df/dt>4

Delta I2 Low

Delta I2 High

Delta I1 Low

Delta I1 High

I2 Low

I2 High

I1 Low

I1 High

V2 Low

V2 High

Z2 Low

Z2 High

Z3 Low

Z3 High

Z4 Low

Z4 High

Zp Low

Zp High

[Binary Flag (32) Indexed String]

Displays the status of the second 32 start signals.

Start Elements 2 FF 0A
