Appendix B - Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
[Courier Number (time-seconds)]
Displays time from protection trip to undercurrent elements indicating the CB is open
Relay Trip Time FF 13
Relay Trip Time
[Courier Number (time-seconds)]
Displays time from protection start to protection trip
Fault Location FF 14
Fault Location
[Courier Number (metres)]
Displays fault location in metres.
Fault Location FF 15
Fault Location
[Courier Number (miles)]
Displays fault location in miles.
Fault Location FF 16
Fault Location
[Courier Number (impedance)]
Displays fault location in ohms.
Fault Location FF 17
Fault Location
[Courier Number (percentage)]
Displays fault location in percentage.
CB2 Operate Time FF 18
CB2 Operate Time
[Courier Number (time-seconds)]
Displays time from protection trip to undercurrent elements indicating the CB2 is open
Start Elements 3 FF 19
V1>2 Cmp Start
Start I>>Diff
Start IN>NDiff
StubBus Start
[Binary Flag (32) Indexed String]
Displays the status of the third 32 start signals.
Start Elements 3 FF 1A
V1>2 Cmp Start
Start I>>Diff
Start IN>NDiff
StubBus Start
[Binary Flag (32) Indexed String]
Displays the status of the third 32 start signals.
IA Angle Pre Flt
IA Angle Pre Flt
[Courier Number (current)]
IA Angle Pre Flt FF 1E
IA Angle Pre Flt
[Courier Number (degrees)]
IB Angle Pre Flt FF 1F
IB Angle Pre Flt
[Courier Number (current)]
IB Angle Pre Flt FF 20
IB Angle Pre Flt
[Courier Number (degrees)]
IC Angle Pre Flt FF 21
IC Angle Pre Flt
[Courier Number (current)]
IC Angle Pre Flt FF 22
IC Angle Pre Flt
[Courier Number (degrees)]
IN Angle Pre Flt FF 23
IN Angle Pre Flt
[Courier Number (current)]
IN Angle Pre Flt FF 24
IN Angle Pre Flt
[Courier Number (degrees)]
IM Angle Pre Flt FF 25
IM Angle Pre Flt
[Courier Number (current)]
