P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B219
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Measured parameter
IM Angle Pre Flt FF 26
IM Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VA Pre Flt FF 27
VA Pre Flt
[Courier Number (voltage)]
Measured parameter
VA Angle Pre Flt FF 28
VA Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VB Pre Flt FF 29
VB Pre Flt
[Courier Number (voltage)]
Measured parameter
VB Angle Pre Flt FF 2A
VB Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VC Pre Flt FF 2B
VC Pre Flt
[Courier Number (voltage)]
Measured parameter
VC Angle Pre Flt FF 2C
VC Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VN Pre Flt FF 2D
VN Pre Flt
[Courier Number (voltage)]
Measured parameter
VN Angle Pre Flt FF 2E
VN Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
IA Fault FF 2F
IA Fault
[Courier Number (current)]
Measured parameter
IA Angle Fault FF 30
IA Angle Fault
[Courier Number (degrees)]
Measured parameter
IB Fault FF 31
IB Fault
[Courier Number (current)]
Measured parameter
IB Angle Fault FF 32
IB Angle Fault
[Courier Number (degrees)]
Measured parameter
IC Fault FF 33
IC Fault
[Courier Number (current)]
Measured parameter
IC Angle Fault FF 34
IC Angle Fault
[Courier Number (degrees)]
Measured parameter
IN Fault FF 35
IN Fault
[Courier Number (current)]
Measured parameter
IN Angle Fault FF 36
IN Angle Fault
[Courier Number (degrees)]
Measured parameter
IM Fault FF 37
IM Fault
[Courier Number (current)]
Measured parameter
IM Angle Fault FF 38
IM Angle Fault
[Courier Number (degrees)]
Measured parameter
VA Fault
FF
39
VA Fault
