Appendix B - Settings and Signals
P54A/B/C/E
B220
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
[Courier Number (voltage)]
Measured parameter
VA Angle Fault FF 3A
VA Angle Fault
[Courier Number (degrees)]
Measured parameter
VB Fault FF 3B
VB Fault
[Courier Number (voltage)]
Measured parameter
VB Angle Fault FF 3C
VB Angle Fault
[Courier Number (degrees)]
Measured parameter
VC Fault FF 3D
VC Fault
[Courier Number (voltage)]
Measured parameter
VC Angle Fault FF 3E
VC Angle Fault
[Courier Number (degrees)]
Measured parameter
VN Fault FF 3F
VN Fault
[Courier Number (voltage)]
Measured parameter
VN Angle Fault FF 40
VN Angle Fault
[Courier Number (degrees)]
Measured parameter
IA Local FF 41
IA Local
[Courier Number (current)]
Measured parameter
IB Local FF 42
IB Local
[Courier Number (current)]
Measured parameter
IC Local FF 43
IC Local
[Courier Number (current)]
Measured parameter
IA remote 1 FF 44
IA remote 1
[Courier Number (current)]
Measured parameter
IB remote 1 FF 45
IB remote 1
[Courier Number (current)]
Measured parameter
IC remote 1 FF 46
IC remote 1
[Courier Number (current)]
Measured parameter
IA remote 2 FF 47
IA remote 2
[Courier Number (current)]
Measured parameter
IB remote 2 FF 48
IB remote 2
[Courier Number (current)]
Measured parameter
IC remote 2 FF 49
IC remote 2
[Courier Number (current)]
Measured parameter
IA Differential FF 4A
IA Differential
[Courier Number (current)]
Measured parameter
IB Differential FF 4B
IB Differential
[Courier Number (current)]
Measured parameter
IC Differential FF 4C
IC Differential
[Courier Number (current)]
Measured parameter
