GE PACE6000 User Manual

3 Operation
K0443 Revision A 3 - 6 [EN] English
3.4 Control Mode
In measure mode, press and the instrument changes to control mode.
Press and the instrument stops controlling pressure and changes to measure mode:
Key to display:
1 Current measured pressure value (in limits green, out of limits blue).
2 In active control mode.
Pressure reading filter ON.
Head (pressure) value applied.
Control mode with overshoot.
SUPPLY
OUTLET VENT REF
+-
Module 2
SUPPLY
OUTLET VENT REF
+-
Module 1
Pressure
output
Pressure
source
Pressure
regulator
Pressure
regulator
Rear view of
PACE6000
instrument
Control
Measure
1
2
3
4
5
6
7
