Door
To remove the door components:
1. Remove the 2 Phillips-head screws from the
hinge cover.
2. Remove the 2 Phillips-head screws that hold the
door to the hinge door plate.
(Continued Next Page)
Hinge Cover
4. Lift and unsnap the door cover from the door
frame.
5. Lift the door glass out of the door frame.
Note: Place the door on a soft, protected fl at
surface so that the door glass faces up. (The door
should rest on the handle side.)
3. Remove the 10 Phillips-head screws (3 not
shown) that hold the door cover and door strike
to the door frame.
Door Glass
To Next Page
