IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
5 - 62 Section 5-9 - Back End Processor (BEP)
5-9-13-5 Output Voltages
• +48V
• +12V
•+5V
• +3.3V
•+5Vstby
5-9-13-6 LEDs on BEP6 Power Supply
Nine LEDs on the BEP6 Power Supply can be viewed through holes in the BEP6 Front Cover.
For description of the LEDs, refer to the label on the BEP6’s Front Cover or to:
5-9-12-2 "LEDs on the BEP6’s Side Cover" on page 5-59.
