IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 5 - Components and functions (theory) 5 - 63
5-9-14 IO Board
5-9-14-1 General description
Different I/O Boards are used for BEP6 and BEP5:
The BEP6 I/O Board has two connectors for connection to the BEP6 Motherboard.
The IO Board is interfaceing between the:
BEP and the connectors on the rear side of VIVID E9 (video/audio/USB)
BEP and the Top Console
BEP and the internal printer
Audio for the speakers, the rear plugs and the DVR
(BEP5 I/O ONLY) Boundary Scan from the BEP to boards in the Front End Card Rack
5-9-14-2 Location in the unit
At the rear of the BEP with the Rear panel available at the rear of the VIVID E9 / VIVID E7.
5-9-14-3 Input DC voltages
Internal in BEP from the BEP Power Supply.
