IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 6 - Service adjustments 6 - 7
6-4-6 Test Images
Select Page 2 of 2 on the Utility screen.
• Turn the second rotary from the left side, to select between the Test Images. The Test Images are
reproduced in Table 6-2.
Figure 6-8 Select Test Image
Table 6-2 Test Images sheet 1 of 3
TEST IMAGE No. TEST IMAGES DESCRIPTION
1.
Test - Standard
2.
Test - Red grades
