GE
D
IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
8 - 230 Section 8-11 - Back End Processor (BEP) parts replacement
8-11-1-2 Preparations
When preparing for the replacement, you must perform the following steps:
1.) Record the VIVID E9 / VIVID E7’s TCPIP settings and installed Option strings.
2.) Export the Patient Archive images to a server or to external media.
3.) Back up the Report Archive, User-Defined Configuration (Customer Presets), and Service
settings.
4.) -100.If possible, wipe the HDD partitions as described here: Reload the system software from DVD.
Select A: to overwrite all content on HDD.
5.) Power down the VIVID E9 / VIVID E7.
6.) Disconnect the Mains Power Cable from the wall outlet.
7.) Disconnect all probes and external I/O cabling.
8.) Disconnect all probes.
9.) Remove the Side Covers.
10.)Remove the Top Cover.
11.)Remove the B/W Printer.
- Disconnect the Power Cable from the rear of the printer.
- Disconnect the signal cable from the I/O panel.
- Loosen the printer bracket wing nut.
- Slide the printer (with signal cable) forward, out of the VIVID E9 / VIVID E7.
12.)For easier access in the next steps, remove the VIVID E9 / VIVID E7’s Front Cover.
