8-11-4-6 Removing the Video Bypass Board in the BEP6
1.) Unscrew and remove the fixing screws from the connector at top of the Video Bypass Board.
2.) Pull out the Video Bypass Board.
8-11-4-7 Installing the Video Bypass Board in the BEP6
1.) Plug in the (new) Video Bypass Board.
2.) Insert and fasten the fixing screw.
3.) Install the BEP Cover as described in these steps:
a.) Insert the base of the BEP Cover inside the base of the BEP.
Be sure the bottom lip of the BEP Cover rests inside the BEP.
b.) Tilt the top of the BEP Cover toward the VIVID E9 / VIVID E7.
c.) Install the fixing screw(s) for the BEP Cover:
- On BEP6 there are two finger screws on the top of the BEP Cover.
4.) Replace the Left Side Cover.
5.) Connect the Mains Power Cable to the wall outlet.
6.) Power up the VIVID E9 / VIVID E7.
7.) Install the BEP Cover as described in these steps:
a.) Insert the base of the BEP Cover inside the base of the BEP.
Be sure the bottom lip of the BEP Cover rests inside the BEP.
b.) Tilt the top of the BEP Cover toward the VIVID E9 / VIVID E7.
c.) Install the fixing screw(s) for the BEP Cover:
- On BEP6 there are two finger screws on the top of the BEP Cover.
Be careful not to pinch any of the cables when installing the BEP Cover.
Be careful not to pinch any of the cables when installing the BEP Cover.
