IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 2 - Site preparations 2 - 11
2-3-2 Required facility needs
NOTE: GE requires a dedicated power and ground for the proper operation of its Ultrasound
equipment. This dedicated power shall originate at the last distribution panel before the system.
The VIVID E9 / VIVID E7 will function on voltages from 100-240 Volts and 50 or 60 Hz. However, if using
220 volt power in North America, then a center tapped power source is required.
Sites with a mains power system with defined Neutral and Live:
The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and a full
size ground wire from the distribution panel to the Ultrasound outlet.
Sites with a mains power system without a defined Neutral:
The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and a full
size ground wire from the distribution panel to the Ultrasound outlet.
• Dedicated single branch power outlet of adequate amperage (see Table 2-2 on page 2-5) meeting
all local and national codes which is located less than 2.5 m (8 ft.) from the unit’s proposed location
• Door opening is at least 76 cm (30 in) wide
• Proposed location for unit is at least 0.3 m (1 ft.) from the wall for cooling
• Power outlet and place for any external peripheral are within 2 m (6.5 ft.) of each other with
peripheral within 1 m of the unit to connect cables.
NOTE: VIVID E9 / VIVID E7 has two outlets inside the unit, one is for the B/W printer and one spare.
• Power outlets for other medical equipment
• Power outlets for test equipment within 1 m (3.2 ft.) of unit
• Clean and protected space to store probes (in their cases or on a rack)
• Material to safely clean probes (done with a plastic container, never metal)
