Completing the setup
Vivid T9/Vivid T8 – Basic Service Manual 3-19
5795591-100 English Rev. 3
3-6 Completing the setup
3-6-1 Purpose of this section
This section describes how to complete the installation of Vivid
T9/Vivid T8.
3-6-2 Contents in this section
• 3-6-3 ‘System specifications’ on page 3-19
• 3-6-4 ‘Electrical specifications’ on page 3-20
• 3-6-5 ‘Connections on the I/O Rear Panel’ on page 3-21
• 3-6-6 ‘Connecting probes’ on page 3-22
• 3-6-7 ‘Powering the system’ on page 3-22
3-6-3 System specifications
3-6-3-1 System requirements verification
• Verify that the site meets the requirements listed in
Chapter 2.
(See: 2-3 ‘Facility needs’ on page 2-12.)
• Verify that the specifications below don’t conflict with any
on-site conditions.
3-6-3-2 Physical dimensions
3-6-3-3 Console Weight
• Weight: approx. 65 kg (144 lbs)
Table 3-6: Physical dimensions of Vivid T9/Vivid T8
Height Width Depth Depth
1250 700 900
mm
49.3 27.6 35.5
Inches
