GE RAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
4-40 Section 4-7 - Peripheral Checks
32.)Screw 9 screws under the KEYBOARD BASE.
33.)Reassemble 5 probe holders
Figure 4-60 Assembling 5 probe holders
34.)Screw 2 screws to assemble SPEAKER COVER LEFT AND RIGHT.
Figure 4-59 Screwing 9 screws under the KEYBOARD BASE
Figure 4-61 Screwing 2 screws to assemble SPEAKER COVER LEFT AND RIGHT
