GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-43

6.) Remove 2 RUBBER CAPS on SPEAKER COVER LEFT/RIGHT.

7.) Unscrew 2 screws and then remove the SPEAKER COVER LEFT/RIGHT. Refer to figure below.

Figure 8-51 Assembling 2 RUBBER CAPS on SPEAKER COVER LEFT/RIGHT

Figure 8-52 Unscrewing 2 screws to remove SPEAKER COVER LEFT/RIGHT
