GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-82 Section 8-24 - Replacement of ASSY Bumper Base Rubber

3.) Remove the TOP CABINET COVER BT16. Refer to the figure below.

4.) Remove the REAR CABINET BEZEL ASSY BT16. Refer to the figure below.

Figure 8-121 Remove the TOP CABINET COVER BT16

Figure 8-122 Remove the REAR CABINET BEZEL ASSY

TOP CABINET COVER BT16

REAR CABINET BEZEL ASSY

BT16
