GE Voluson P8 - Page 535

To Next Page

To Previous Page

GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-173

4.) Unplug all cables and Unscrew 7 screws and remove the NEST EMI BRKT BT16.

5.) Remove 3 RS KNOBS .

Figure 8-247 Unpluging all cables and removing the NEST EMI BRKT BT16

Figure 8-248 Removing 3 RS Knobs
