GE XMTC User Manual

Chapter 3. Operation and Programming
XMTC User’s Manual 42
IDM
Data
Global
Help
...More OpƟons...
Connect to a...
Edit FuncƟons
Upload/Download
Real-Time
System
Error Handler
Factory Cal
Edit Point X
Edit # of Points
Delete
Add
% Gas
[Next Item]
[Next Item]
x01 Gas mV
[Next Item]
x10 Gas mV
[Next Item]
Advanced
Language
Fast Response
Password
Meter ID
Number
[Next Item]
NoYes
Fast Tau Up
[Next Item]
Fast Tau Down
[Next Item]
Fast Threshold %FS
[Next Item]
Download from PC
Upload to PC
Reset to Defaults
Filename
[Next Item]
Gas mV under range
DriŌ/Cal Err
Gas mV over range
Total DriŌ Error
Gas % under range
Gas % over range
mA Enable mA Disable
Set Error mA Output
[Next Item]
IDM Enable IDM Disable
NOTE: Click [Exit Page] or [Previous Item] at any Ɵme to abort the current operaƟon.
Menu Item
Command Menu OpƟon
Data Entry Window
[Previous Item]
Return to Previous Window
[Next Item/Enter]
ConĮrm/Accept Current Entry
[Exit Page]
Return to Command Menu
KEY/LEGEND
Figure 52: Error Handler, Factory Cal and Advanced Menu Map
