ADD JUMPER FROM U3
PIN 2 TO U3 PIN 5
SEE DETAIL "B"
FOR 710-1276 REV A, B, C ONLY
DETAIL "A"
P7
78
1
SEE DETAIL "B"
COMPONENT SIDE VIEW
SEE NOTE 4
FOR U3 REWORK
SEE DETAIL "A"
DETAIL "B"
SOLDER SIDE VIEW
SEE NOTE 2
SEE NOTE 2
INSTALL C35 ATOP
FOR 710-1276 REV A, B, C ONLY
OR ASIDE R3
SOLDER SIDE VIEW
1
REF
REF ONLY
CHANGES TO THIS DRAWING MAY REQUIRE PRIOR AGENCY (FM/CSA)
AUTHORIZATION. REFER TO CERTIFICATION DRAWING 752-107
AND CONTACT THE CERTIFICATION ENGINEER.
GROUPS
NUMBER
DESCRIPTION
04 OX + PRESS
03 OX
02 TC
01 STANDARD
NOTES:
1. ASSEMBLE PER IPC-A-610 AND/OR PANAMETRICS STANDARD 957-002.
2. INSTALL C29 AND C30 ON SOLDER SIDE OF BOARD AS SHOWN.
C29 MAY EXTEND OVER THE EDGE OF THE PCB 0.14" MAX.
3. TRIM J6 AND J7 LEADS TO 0.04 INCHES MAX HEIGHT ABOVE THE PCB.
4. INSTALL VR3 AT CR2 LOCATION AND INSTALL VR4 AT CR4 LOCATION.
