Appendix A. Supplemental Information
56 XMTC User’s Manual
A.4 Sample Calibration Sheet
A typical calibration sheet example is shown in Figure 55 below.
Figure 55: A Sample Calibration Sheet
XMTC Calibration Sheet
XMTC S/N: 2630
XMTC Part Number: XMTC-62-11
Calibration Part Number: XMTC-CAL-311
Calibration Gases: H2/N2
Calibration Ranges: 0 to 5%
Work Order Number: 508230006418
Calibration Date: April 24, 2009
Technician: K. Brin
Unit Calibrated Using x10 Gain Scale
XMTC Calibration Data
Hydrogen in Nitrogen
PT %H2 x10 (mV) Output (mA)
1 0.00 -56.02 4.00
2 5.00 574.00 20.00
Output:
4 to 20 mA 0 to 5% H2 in N2
Clamp Output:
No
Field Calibration.
Zero:
100% N2
Span:
5% H2 in N2
