Item Designation Material 2" IPS 3" IPS 4" IPS 6" IPS
36 Locking ring 1.4301 -- -- -- --
43 Clamp join KL 1.4401 221-507.04 221-507.03 221-507.11 221-507.14
46 Clamp join KL 1.4401 221-507.06 221-507.09 221-507.06 221-507.11
65 Seal ring EPDM 924-305 221-367.03 221-367.04 221-367.06
FKM 924-307 221-367.08 221-367.09 221-367.11
HNBR 924-333 221-367.15 221-367.15 221-367.14
66 Guide ring Turcite 935-056 935-078 935-076 935-072
Guide ring 3A MF6 935-117 935-120 935-119 935-118
74 Cleaning nozzle PVDF 221-334.01 221-334.02 221-334.02 221-334.03
92 Balancer fastener 1.4404 221-348.03 221-538.01 221-538.02 221-538.04
94* V-ring RA EPDM 221-365.07 221-365.08 221-365.09 221-365.16
FKM 221-365.10 221-365.11 221-365.12 221-365.17
HNBR 221-365.18 221-365.20 221-365.19 --
401 Housing V1 1.4404 221-101.37 221-101.35 221-101.36 221-101.17
402 Housing V2 1.4404 221-102.62 221-102.59 221-102.60 221-102.17
A Actuator VARIVENT® See spare parts list/dimensions sheet for VARIVENT® actuator
B Control top T.VIS® See parts list for control top T.VIS®
Items 92 and 66 are omitted on sterile lock BU See spare parts list for sterile lock BU
Items 3 and 66 are omitted on sterile lock BO See spare parts list for sterile lock BO
Grease RIVOLTA F.L.G. 100g tube not included with sealing set.
** Do not grease item 7 and 8
413-136
1) The sealing set includes items 1, 5, 6, 7, 8, 22, 23, 24, 29 and 29.1
Spare parts list - Double seat valve R
430BAL008386EN_3
07.02.2022 73
