Sealing sets for VARIVENT® double seat valve R
Item Qty Designation Material
DN 25
1"
DN 40/50
1.5"/2"
DN 65/80
2.5"/3"
DN 100
4"
DN 125
DN 150
6"
1 1 Seal ring EPDM 924-084 924-084 924-085 924-085 924-088 924-088
FKM 924-082 924-082 924-083 924-083 924-087 924-087
HNBR 924-311 924-311 924-313 924-313 -- --
5 4 O-ring EPDM 930-309 930-144 930-150 930-156 930-372 930-260
FKM 930-168 930-171 930-176 930-178 930-409 930-259
HNBR 930-632 930-633 930-634 930-863 -- --
6 1 O-ring NBR 930-004 930-004 930-004 930-004 930-007 930-007
**7 1 V-ring EPDM 932-046 932-021 932-024 932-028 932-060 932-042
FKM 932-030 932-033 932-035 932-039 932-062 932-041
HNBR 932-087 932-088 932-090 932-100 -- --
**8 1 V-ring EPDM 932-017 932-019 932-023 932-027 932-059 932-045
FKM 932-029 932-032 932-034 932-038 932-063 932-044
HNBR 932-085 932-084 932-089 932-099 -- --
22 1 O-ring EPDM 930-268 930-268 930-268 930-243 930-356 930-356
FKM 930-164 930-164 930-164 930-244 930-357 930-357
HNBR 930-639 930-639 930-640 930-640 -- --
23 1 O-ring EPDM 930-525 930-246 930-246 930-246 930-266 930-266
FKM 930-802 930-247 930-247 930-247 930-265 930-265
HNBR 930-636 930-631 930-631 930-631 -- --
24 1 O-ring EPDM 930-368 930-235 930-235 930-235 930-268 930-268
FKM 930-616 930-162 930-162 930-162 930-164 930-164
HNBR 930-635 930-638 930-638 930-638 930-639 930-639
29 1 O-ring NBR 930-026 930-026 930-026 930-026 930-035 930-035
29.1 1 O-ring NBR 930-026 930-026 930-026 930-026 930-026 930-026
65 1 Seal ring EPDM 924-084 924-305 221-367.03 221-367.04 221-367.05 221-367.06
FKM 924-082 924-307 221-367.08 221-367.09 221-367.10 221-367.11
HNBR 924-311 924-333 221-367.15 221-367.14 -- --
94 1 V-ring RA EPDM 221-365.13 221-365.07 221-365.08 221-365.09 221-365.14 221-365.16
FKM 221-365.21 221-365.10 221-365.11 221-365.12 221-365.15 221-365.17
HNBR 221-365.24 221-365.18 221-365.20 221-365.19 -- --
Sealing set complete
EPDM 221-528.74 221-511.32 221-001693 221-001687 221-001689 221-001692
FKM 221-001424 221-519.11 221-001695 221-001688 221-001690 221-001691
HNBR 221-004163 221-000752 221-004165 221-004166 -- --
Grease RIVOLTA F.L.G. 100g tube not included with sealing set.
** Do not grease item 7 and 8
413-136
Storage instructions: storage in accordance with DIN 7716
Relative humidity approx. 65%, temperature 15-25°C and protected from light
When replacing seals, observe the instructions in the instruction manual!
429-009
Spare parts list - Double seat valve R
430BAL008386EN_3
74 07.02.2022
