page | 8
Getting Started
Installation
Sample Application Diagram
EXT-UHD600-41
HDMI CABLE
Ultra HD
Source
Ultra HD
Source
Ultra HD
Source
Ultra HD
Source
Ultra HD 600 MHz
4x1 Switcher for HDMI
w/HDR
Ultra HD
Display
CAT-5 CABLE
LAN
(for IP Control)
RS-232 Controller
RS-232 CABLE
EXT-RMT-EXTIRN
IR Extender
OR
IR
Automation
Control Device
