114
MAINTENANCE
Every 100 Hours
Cleaning the Water Separator
(CTL60 / CTL80)
WARNING
¡¡
¡¡
¡Do not smoke or permit open flames
while handling fuel or working on the
fuel system.
¡¡
¡¡
¡Stop the engine in a well-ventilated
place and allow it to cool down before
performing maintenance.
¡¡
¡¡
¡Clean up spilled fuel immediately.
S : Closed
1. Open the rear door.
2. Close the valve (2).
3. Loosen the ring (3), then remove the case
(4), element (5) and indicator ring (6) and
clean them.
4. Inspect the O-ring, and if there are any
scratches or other irregularities, replace
it.
5. Assemble the indicator ring (6), case (4)
and element (5) and tighten the ring (3).
6. Open the valve (2).
7. Loosen the vent plug (8) and bleed the
air.
8. Tighten the vent plug (8).
Refer to page 137 “Bleeding the Air from the
Fuel System”.
ON
OFF
6
3
S
5
4
2
1
7
8
T7G0062
To Next Page
